Frymaster LOV - Page 11

1 From RTI transformer 24VAC Black
2 Common White
3
4 To Waste Solenoid - 3 Way 24VAC Brown
5
6 RTI JIB Valve Fill Solenoid
24VAC
Green
7 Ground - Fill Solenoid
J7 From RTI Box
8
From RTI "Waste Tank Full
Sensor" Test Pins 1 to 8
0VDC –
Full
5VDC –
Not Full Red
11
