5-12
* The table below lists the factory settings of "Fuji's standard torque boost," "Nominal rated current of
Fuji standard motor," and "Nominal rated capacity of Fuji standard motor" in the "Default setting"
column of the above tables.
Table 5.1 Fuji Standard Motor Parameters
Fuji's standard
torque
boost (%)
Nominal rated current of
Fuji standard motor (A)
Nominal rated
capacity of Fuji
standard motor
(kW)
Function codes
F11, E34 and P03
Shipping destination (version)
Power
supply
voltage
Nominal
applied
motor
(kW)
Inverter type
Function code
F09
Asia EU Japan
Function code
P02
0.1 FRN0.1C1
-2
8.4 0.62 0.68 0.61 0.1
0.2 FRN0.2C1
-2
8.4 1.18 1.30 1.16 0.2
0.4 FRN0.4C1
-2
7.1 2.10 2.30 2.13 0.4
0.75 FRN0.75C1
-2
6.8 3.29 3.60 3.36 0.75
1.5 FRN1.5C1
-2
**
6.8 5.55 6.10 5.87 1.5
2.2 FRN2.2C1
-2
**
6.8 8.39 9.20 8.80 2.2
Three-
phase
200 V
3.7 FRN3.7C1
-2
**
5.5 13.67 15.00 14.38 3.7
0.4 FRN0.4C1
-4
7.1 1.09 1.15 1.07 0.4
0.75 FRN0.75C1
-4
6.8 1.71 1.80 1.68 0.75
1.5 FRN1.5C1
-4
**
6.8 3.04 3.05 2.94 1.5
2.2 FRN2.2C1
-4
**
6.8 4.54 4.60 4.40 2.2
Three-
phase
400 V
3.7
4.0
FRN3.7C1
-4
**
FRN4.0C1
-4
**
5.5 7.43 7.50 7.20 3.7
0.1 FRN0.1C1
-7
8.4 0.62 0.68 0.61 0.1
0.2 FRN0.2C1
-7
8.4 1.18 1.30 1.16 0.2
0.4 FRN0.4C1
-7
7.1 2.10 2.30 2.13 0.4
0.75 FRN0.75C1
-7
6.8 3.29 3.60 3.36 0.75
1.5 FRN1.5C1
-7
6.8 5.55 6.10 5.87 1.5
Single-
phase
200 V
2.2 FRN2.2C1
-7
6.8 8.39 9.20 8.80 2.2
0.1 FRN0.1C1
-6
8.4 0.62 0.68 0.61 0.1
0.2 FRN0.2C1
-6
8.4 1.18 1.30 1.16 0.2
0.4 FRN0.4C1
-6
7.1 2.10 2.30 2.13 0.4
Single-
phase
100 V
0.75 FRN0.75C1
-6
6.8 3.29 3.60 3.36 0.75
Note 1) A box (
) in the above table replaces S or E depending on the enclosure.
2) A box (
) in the above table replaces A, C, E, or J depending on the shipping destination.
3) Asterisks (**) in the above table denote the following:
21: Braking resistor built-in type (Available for inverters with 1.5 kW or above)
None: Standard
