Fuji Xerox ApeosPort-IV C3375 Administration Guide

Replacing Consumables
71
Maintenance
3
9 Slowly slide out the cleaning bars housed within
the LED printhead until it stops. The cleaning bars
are located in the cleaning connection just under
the drum cartridges (R1, R2, R3, or R4).
Note • Slide out the cleaning bars until you see "zzz".
Important •Do not remove the cleaning bars from the
housing.
10 Slowly slide the cleaning bars back into place.
Note • Clean the four LED printheads (R1 to R4) by
sliding the cleaning bars back and fourth for two
or three times, respectively.
11 Return the cover to the original position.
Note • Push the cover until it clicks into place.
12 Rotate the release lever clockwise to lock the
cover.
13 Close the front cover.
Note • If the front cover is not closed completely, a message appears and the machine will remain paused.
Replacing Drum Cartridges R1, R2, R3, or R4 (for Customers Having a Spot
Maintenance Contract)
The machine displays the following messages when a drum cartridge needs to be replaced.
When the message is displayed, contact our Customer Support Center.
Refer to this section and locate the position or the indicated drum cartridge (R1, R2, R3, or
R4), and replace the drum cartridge.

Fuji Xerox ApeosPort-IV C3375 Specifications

General

Print Resolution	1200 x 2400 dpi
Functions	Print, Copy, Scan, Fax
Duplex Printing	Yes
Memory (Standard)	2 GB
Copy Resolution	600 x 600 dpi
Scan Resolution	600 x 600 dpi
Fax Transmission Speed	33.6 kbps
Operating System Compatibility	Windows, Mac OS, Linux
Print Speed	35 ppm
Connectivity	Ethernet, USB
Paper Size	A3, A4, A5, B4, B5
Hard Drive	160 GB
Network Connectivity	Ethernet
Copy Speed (Color)	35 cpm
Copy Speed (Mono)	35 cpm
