Appendix
728
Appendix
16
Start Time The date and time that the communication began are shown. In
Batch Send, the start time of the transmission for each document
is recorded.
Duration The duration of the transmission is displayed. In Batch Send, it is
the length of time taken to transmit each document is recorded.
Pages "-" is shown when the number of pages is 0.
z
Transmitting
The number printed on the left side of the slash "/" indicates the
number of pages that were successfully transmitted. The
number printed on the right side of the slash "/" indicates the
number of total pages. In Batch Send, the number of total
pages is not shown.
z
Receiving/Polling
The number of pages that the machine successfully received is
shown.
z
Depending on the transmission status on the recipient's machine or
the setting of the machine, the value in [Pages] may differ from the
actual number of pages printed.
Mode The mode used for the communication is shown.
There are three modes: G3, EC, and SG3 (Super G3). (Thisfield is
blank if a mode other than above these was used.)
When IP Fax (SIP) is used:
IP Fax or IP Fax-ECM
Contents The information about the communication is indicated. See the
Note field at the bottom of the report for a list of abbreviations
and their definitions.
z
Transmitting
1 Remote service
2 Redial
3 Folder XXX
4 Broadcast/Multi-Poll
5 Polling
6 Relay Broadcast Assignment
7 Fax forwarding box XXX
When IP Fax (SIP) is used:
1 Redial
2 Folder XXX
3 Broadcast/Multi-Poll
4 Polling
z
Receiving
1 Folder XXX
2 Polling
3 Receiving line box XXX
When IP Fax (SIP) is used:
1 Folder XXX
2 Polling
3 Receiving line box XXX
z
XXX indicates the Folder number
Status The result of the operation is indicated.
Completed : The operation ended normally.
Busy : The recipient is busy or did not answer.
Item Description
To Next Page
