(E codes continued)
Code
Name
Data setting range
Incre-
ment
Unit
Change
when
running
Data
cop
ying
De
fault
setting
E37
Current Detection 2
(Level)
(Timer)
0.00 (Disable), 0.01 to 100.0
Current value of 1 to 200% of the inverter
rated current
0.01
A
Y
Y1
Y2
See
Table
A.
E38
0.01 to 600.00 *1
0.01
s
Y
Y
10.00
E39
Coefficient for Constant
Feeding Rate Time
0.000 to 9.999
0.001
–
Y
Y
0.000
E40
PID Display Coefficient
A
-999 to 0.00 to 9990 *2 0.01 – Y Y 100
E41
PID Display Coefficient
B
-999 to 0.00 to 9990 *2
0.01
–
Y
Y
0.00
E42 LED Display Filter 0.0 to 5.0 0.1 s Y Y 0.5
E43 LED Monitor
(Display item)
0: Speed monitor (select by E48)
3: Output current
4: Output voltage
10: PID command
12: PID feedback amount
13: Timer
14: PID output
– – Y Y 0
E48 LED Monitor
(Speed monitor item)
0: Output frequency (Before slip
compensation)
1: Output frequency (After slip
compensation)
2: Reference frequency
4: Load shaft speed in r/min
5: Line speed in m/min
6: Constant feeding rate time
– – Y Y 0
E50
Coefficient for Speed
Indication
0.01 to 200.0 *1
0.01
–
Y
Y
30.00
E52
Keypad
(Menu display mode)
0: Function code data editing mode
(Menu #1)
1: Function code data check mode
(Menu #2)
2: Full-menu mode (Menus #0 through
#6)
– – Y Y 0
(Note) E45, E46 and E47 appear on the LED monitor, but cannot be used by this inverter.
*1 When you make settings from the keypad, the incremental unit is restricted by the number of digits that the LED
monitor can display.
(Example) If the setting range is from -200.00 to 200.00, the incremental unit is:
"1" for -200 to -100, "0.1" for -99.9 to -10.0 and for 100.0 to 200.0, and "0.01" for -9.99 to -0.01 and for 0.00 to 99.99.
*2 The significant figure is in three digits, so the incremental unit changes depending upon the magnitude of absolute values.
(Example) The incremental unit is "10" for 1000 to 9990, "1" for -999 to -100 and for 100 to 999, "0.1" for -99.9 to -10.0 and
for 10.0 to 99.9, and "0.01" for -9.99 to 9.99.
