Connect the monitor, mouse and keyboard Preparing for use
A26361-K520-Z300-3-7619 9
Connecting the mouse
Depending on the equipment level selected, your PC will be supplied with a PS/2 mouse or a USB
mouse.
Connecting a PS/2 mouse
Ê Connect the PS/2 mouse to the PS/2 mouse port of the PC.
Connecting USB mouse
Ê Connect the USB mouse to the USB port of the PC.
i
If you do not attach a mouse at the PS/2 mouse port, you can disable the mouse
controller in the BIOS Setup in order to free the IRQ12 for a different application.
Connecting a keyboard
Depending on the equipment level selected, your PC will be supplied with a standard keyboard or a
USB keyboard.
Connecting standard keyboard
Use the supplied keyboard cable only.
Ê Plug the other end of the keyboard cable (square plug) into the socket on the underside of the
keyboard.
Ê Plug the round plug of the keyboard cable into the keyboard port of the PC.
Connecting USB keyboard
Use the supplied keyboard cable only.
Ê Plug the other end of the keyboard cable (square plug) into the socket on the underside of the
keyboard.
Ê Insert the rectangular USB plug of the keyboard cable into the USB port of the PC.
