Installing and removing drives System expansions
A26361-K520-Z300-3-7619 41
Installing an accessible drive
Ê Open the casing (see "Opening the casing").
i
Should the SmartCard reader get in the way of the accessible drive during installation,
then remove the reader (see "Installing/removing a SmartCard reader").
A
B
1
2
Ê Pry the plastic drive cover (A) out of the front cover.
Ê Pry the shielding plate (B) on left-hand side out of the bay.
!
Do not throw away the safety covers. If you remove the drive again later, you will have to
reinstall the covers.
Ê Take the new drive out of its packaging.
Ê Make the required changes to the drive settings (if necessary, to the settings of installed drives
as well).
