A26361-K520-Z300-3-7619 57
Technical data
Electrical data
Regulations complied with: EN 60950 / VDE 0805
UL 1950
CSA 22.2 No.950
Protection class: I
Rated voltage range: (selectable) 100 V -127 V / 200 V - 240 V
Frequency: 50 Hz - 60 Hz
Max. rated current
· PC with monitor socket:
· Monitor socket (output)
100 V -127 V / 7,0 A
200 V -240 V / 3.0 A
100 V -127 V / 3 A
200 V -240 V / 1,5 A
Maximum power draw in operation (peak):
Minimum power draw in operation:
Power draw in energy saving mode (ACPI-S3
mode):
Power draw in 'ready-to-operate' mode
(ACPI-S3 mode):
< 144 W *)
< 54 W *)
2.7 W *)
2.7 W *)
Sound emission
· Sound pressure L
pAm
(Idle mode):
· Sound power level L
WAd
(Operation
mode):
· Sound power level L
WAd
(Idle mode):
System board System board
D1327 D1326:
29 dB (A) *) 25 dB (A) *)
50 dB (A) *) 48 dB (A) *)
42 dB (A) *) 40 dB (A) *)
*) These values only apply for a SCENIC eB / SCENIC xB with the configuration below. When
additional or other components are incorporated, the power consumption or the sound
emission (L
WAd
) in energy saving mode may exceed the requirements for the environment
symbol ("Blue Angel") (30 W or 55 dB).
Processor (256 KB cache):
Main memory:
Floppy disk drive:
Hard disk drive:
CD-ROM drive:
DVD drive
Graphics:
LAN:
Pentium III Processor at 1 GHz
128 MB SDRAM
1.44 MB
40 GB, 7200 rpm
48fold
16x
Matrox GM1000-16
Intel 82565, 10/100 Mbit Ethernet controller,
onboard
Dimensions
Width/depth/height: 454 mm/475 mm/138 mm
Weight
with the basic configuration ca. 11 kg (107.9 N) in basic configuration
