System expansions Installing and removing drives
48 A26361-K520-Z300-3-7619
Removing the second hard disk drive
2
1
1
1
Ê Remove the screws (1).
Ê Take the hard disk drive out of the
carrier (2).
Ê Make the required settings on the
remaining hard disk drive
(e.g. stand alone).
Installing the drive cage
4
3
2
1
Ê Connect the data and power supply cables to the hard disk drive or to the hard disk drives.
Ê Lift the drive cage into the system unit in the direction shown by the arrow (1) and push it
forward until it engages (2).
Ê Press the drive cage in the direction of the arrow (3) and press it downward (4).
Ê Close the casing (see "Casing, assembling").
i
You may have to check the entry for the drive in the Setup menu.
