Extensions to the system board System expansions
A26361-K520-Z300-3-7619 55
Installing ventilation duct
3
2
1
Ê Lift the ventilation duct into the unit (1).
Ê Insert the ventilation duct into the guide holes (2) in the power supply.
Ê Push the ventilation duct downward until the clip engages (3).
Ê Close the casing (see "Casing, assembling").
