1-2. Indoor unit connection patterns
¢ 2 units
AOYG14KBTA2
Combination no. Unit 1 Unit 2 Total
1 7 7 14
2 7 9 16
3 7 12 19
4 9 9 18
5 9 12 21
AOYG18KBTA2
Combination no. Unit 1 Unit 2 Total
1 7 7 14
2 7 9 16
3 7 12 19
4 7 14 21
5 9 9 18
6 9 12 21
7 9 14 23
8 12 12 24
9 12 14 26
Numbers in column Unit 1, 2, and Total indicate the indoor unit capacities as follows:
7: 7,000 Btu/h, 9: 9,000 Btu/h, 12: 12,000 Btu/h, 14: 14,000 Btu/h ....
- 5 -
1-2. Indoor unit connection patterns 1. Model lineup
2-UNIT MULTI-SPLIT TYPE 2-UNIT MULTI-SPLIT TYPE
