Combination of external input and output
By combining the function setting of the indoor unit and rotary switch setting of the External Input
and Output PCB, you can select various combinations of functions.
Combination examples of external input and output are as follows:
Mode
Function
setting
External Input
and Output PCB
(Rotary SW)
External input
External Input and Output PCB
CN313 CN314 Signal type
0-1 60-00 1
Operation/Stop Not available Edge
Operation Stop Pulse
0-2 60-00 2
Forced Thermostat
OFF
Not available Edge
1—8
60-01 to
60-08
3 - 9, A (Setting prohibited)
9 60-09 B
Forced Thermostat
OFF
Not available Edge
10 60-10 C
Forced Thermostat
OFF
Not available Edge
11 60-11 D
Forced Thermostat
OFF
Not available Edge
Mode
Function
setting
External Input
and Output PCB
(Rotary SW)
External output
External Input and Output PCB
CN310 CN311 CN312
0-1 60-00 1 Operation/Stop Error status
Indoor unit fan
operation status
0-2 60-00 2 Error status
Indoor unit fan
operation status
Not available
1—8
60-01 to
60-08
3 - 9, A (Setting prohibited)
9 60-09 B Operation/Stop
Indoor unit fan
operation status
Not available
10 60-10 C Operation/Stop Error status Not available
11 60-11 D Operation/Stop
Indoor unit fan
operation status
Error status
NOTE:
Input of Operation/Stop depends on the setting of function setting 46.
00: Operation/Stop mode 1 (Remote controller enabled)
01: (Setting prohibited)
02: Forced stop
03: Operation/Stop mode 2 (Remote controller disabled)
- 133 -
