4-4. Wall mounted type
¢ Models: ASYG07–14KGTB
Unit: mm
834
Outline of indoor unit
327
273273 54
215
3.0
270
43
43
9.5220
for pipe inlet Ø65 for pipe inlet Ø65
182 182
35634648 84
63 63
373.5
417.5
448
- 28 -
4-4. Wall mounted type 4. Dimensions
2-UNIT
MULTI-SPLIT TYPE
2-UNIT
MULTI-SPLIT TYPE
