14-6. IR receiver kit with Wireless remote controller (UTY-
LBTYM: Optional part)
¢
Overview
REG1U
Signal
transmitter
10°C HEAT
button
TEMP.
button
Economy
button
Start/Stop
button
MODE button
ON TIMER button
OFF TIMER button
TIMER SELECT button
SLEEP TIMER button
TIMER CANCEL button
RESET button
TEST RUN button
CLOCK ADJUST button
SWING button
SET button
FAN button
NOTE: Functions may differ by type of the indoor unit. For details, refer to the operation manual.
Display panel
Mode indicator
Clock and Timer indicator
Fan speed indicator
Swing indicator
Temperature indicator
Transmit indicator
To facilitate explanation, the accompanying illustration has been drawn to show all possible indicators;
in actual operation, however, the display will only show those indicators appropriate to the current oper-
ation.
