Fujitsu AOYG14KBTA2 - Model: ARXG09 KSLAP

¢
Model: ARXG09KSLAP
60
50
40
30
20
10
0
300
400
500
600
700
External static pressure (Pa)
Airflow (m
3
/h)
Hi (SP mode 03)
Quiet (SP mode 03)
Quiet (SP mode 00)
SP mode 03
upper limit
SP mode 03
lower limit
Normal SP upper limit
Quiet (Normal SP)
Hi (Normal SP)
Hi (SP mode 00)
SP mode 00 upper limit
*1: Available airflow rate range when Auto louver grille (option) is installed.
Fan speed: HIGH
Vertical airflow direction louver: Up
60
50
40
30
20
10
0
300
External static pressure (Pa)
Airflow (m
3
/h)
400 500
600
700
Available airflow rate range (High level)
*1
Hi (SP mode 00)
Hi (Normal SP)
Hi (SP mode 02)
Hi (SP mode 03)
- 80 -
7-1. Mini duct type 7. Fan performance
2-UNIT MULTI-SPLIT TYPE 2-UNIT MULTI-SPLIT TYPE
