Combination of external input and output
By combining the function setting of the indoor unit and rotary switch setting of the External Input
and Output PCB, you can select various combinations of functions.
Combination examples of external input and output are as follows:
Mode
Function
setting
Rotary
SW
External input
Indoor unit External Input and Output PCB
CN46 CN313 CN314
0-1 60—00 1
Operation/Stop mode1
(Function setting 46-00)
or
Forced stop
(Function setting 46-02)
or
Operation/Stop mode2
(Function setting 46-03)
Operation/Stop Not available
Operation Stop
0-2 60-00 2
Forced thermostat
OFF
Not available
1—8 60-01—08 3—9, A (Setting prohibited)
9 60-09 B Operation/Stop mode1
(Function setting 46-00)
or
Forced stop
(Function setting 46-02)
or
Operation/Stop mode2
(Function setting 46-03)
Forced thermostat
OFF
Not available
10 60-10 C
11 60-11 D (Setting prohibited)
Mode
Function
setting
Rotary
SW
External output
Indoor unit External Input and Output PCB
CN47 CN310 CN311 CN312
0-1 60-00 1 Operation/Stop Operation/Stop Error status
Indoor unit fan
operation status
0-2 60-00 2 Operation/Stop Error status
Indoor unit fan
operation status
Not available
1—8 60-01—08 3—9, A (Setting prohibited)
9 60-09 B Error status
Operation/Stop
Indoor unit fan
operation status
Not available
10 60-10 C
Indoor unit fan
operation status
Error status
11 60-11 D (Setting prohibited)
NOTE:
Input of Operation/Stop depends on the setting of function setting 46.
00: Operation/Stop mode 1 (Remote controller enabled)
01: (Setting prohibited)
02: Forced stop
03: Operation/Stop mode 2 (Remote controller disabled)
- 150 -
