Fujitsu AOYG14KBTA2 User Manual

6. Capacity table
6-1. Combinations
¢
Model: AOYG14KBTA2

Cooling
Combination of indoor
unit
Rated capacity for
each indoor unit
(kW)
Total capacity
(kW)
Input power (kW)
EER
(W/W)
Seasonal data
Unit
Total
Unit
Min. Rated Max. Min. Rated Max.
Pdesign
(kW)
SEER
(kWh/kWh)
Energy effi-
ciency class
1 2 1 2
7 7 14 2.00 2.00 1.4 4.00 4.6 0.25 0.97 1.20 4.12 4.0 8.7 A+++
7 9 16 1.75 2.25 1.4 4.00 4.6 0.25 0.97 1.20 4.12 4.0 8.7 A+++
7 12 19 1.47 2.53 1.4 4.00 4.6 0.25 0.97 1.20 4.12 4.0 8.7 A+++
9 9 18 2.00 2.00 1.4 4.00 4.6 0.25 0.97 1.20 4.12 4.0 8.7 A+++
9 12 21 1.71 2.29 1.4 4.00 4.6 0.25 0.97 1.20 4.12 4.0 8.7 A+++
NOTES:
• 7: 7,000 Btu/h, 9: 9,000 Btu/h, 12: 12,000 Btu/h
• The above is the value for connecting with KG models in wall mounted type.
• 2 or more indoor units should be connected.
• Cooling: Indoor temperature of 27 °CDB/19 °CWB and outdoor temperature of 35 °CDB.
• Pipe length: 5 m, Height difference: 0 m (Outdoor unit—Indoor unit)
• The total ability of connected indoor unit is from 14,000 Btu/h up to 21,000 Btu/h.

Heating
Combination of indoor
unit
Rated capacity for
each indoor unit (kB-
tu/h)
Total capacity
(kBtu/h)
Input power (kW)
COP
(W/W)
Seasonal data
Unit
Total
Unit
Min. Rated Max. Min. Rated Max.
Pdesign
(kW)
SCOP
(kWh/kWh)
Energy effi-
ciency class
1 2 1 2
7 7 14 2.20 2.20 1.1 4.40 5.5 0.25 0.95 1.65 4.63 3.5 4.7 A++
7 9 16 1.92 2.48 1.1 4.40 5.5 0.25 0.95 1.65 4.63 3.5 4.7 A++
7 12 19 1.62 2.78 1.1 4.40 5.5 0.25 0.95 1.65 4.63 3.5 4.7 A++
9 9 18 2.20 2.20 1.1 4.40 5.5 0.25 0.95 1.65 4.63 3.5 4.7 A++
9 12 21 1.89 2.51 1.1 4.40 5.5 0.25 0.95 1.65 4.63 3.5 4.7 A++
NOTES:
• 7: 7,000 Btu/h, 9: 9,000 Btu/h, 12: 12,000 Btu/h
• The above is the value for connecting with KG models in wall mounted type.
• 2 or more indoor units should be connected.
• Heating: Indoor temperature of 20 °CDB, and outdoor temperature of 7 °CDB/6 °CWB.
• Pipe length: 5 m, Height difference: 0 m (Outdoor unit—Indoor unit)
• The total ability of connected indoor unit is from 14,000 Btu/h up to 21,000 Btu/h.
