¢ Models: ASYG07–14KMTB and ASYG07–14KMCC
Unit: mm
Outline of indoor unit
327
273
273 54
43
43
9.5220
for pipe inlet Ø65 for pipe inlet Ø65
182 182
35634648 84
63 63
834
270
222
3.0
359
418
492
- 32 -
4-4. Wall mounted type 4. Dimensions
2-UNIT
MULTI-SPLIT TYPE
2-UNIT
MULTI-SPLIT TYPE
