Fujitsu AOYG14KBTA2 User Manual

Indoor unit connect-
ing capacity
Outdoor temperature
Indoor temperature
18.0 °CDB 21.0 °CDB 23.0 °CDB 27.0 °CDB 29.0 °CDB 32.0 °CDB
12.0 °CWB 15.0 °CWB 16.0 °CWB 19.0 °CWB 21.0 °CWB 23.0 °CWB
kBtu/h °CDB TC IP TC IP TC IP TC IP TC IP TC IP
14
-10.0
3.9 0.63 4.4 0.64 4.7 0.65 5.0 0.65 5.3 0.66 5.5 0.67
0.0 3.9 0.82 4.4 0.83 4.7 0.84 5.0 0.85 5.3 0.86 5.5 0.86
5.0 3.9 0.70 4.4 0.71 4.7 0.71 5.0 0.72 5.3 0.73 5.5 0.73
10.0 3.9 0.38 4.4 0.39 4.7 0.39 5.0 0.40 5.3 0.40 5.5 0.40
15.0 3.9 0.51 4.4 0.52 4.7 0.52 5.0 0.53 5.3 0.53 5.5 0.54
20.0 3.9 0.67 4.4 0.68 4.7 0.69 5.0 0.69 5.3 0.70 5.5 0.71
25.0 3.9 0.83 4.4 0.84 4.7 0.85 5.0 0.86 5.3 0.87 5.5 0.87
30.0 3.9 0.97 4.4 0.98 4.7 0.99 5.0 1.00 5.3 1.01 5.5 1.02
35.0 3.9 1.24 4.4 1.26 4.7 1.27 5.0 1.29 5.3 1.30 5.5 1.31
40.0 3.1 1.01 3.5 1.03 3.7 1.04 3.9 1.05 4.2 1.06 4.3 1.06
46.0 3.1 0.78 3.5 0.79 3.7 0.80 3.9 0.81 4.2 0.82 4.3 0.82
NOTES:
• TC: Total Capacity (kW), IP: Input Power (kW)
• Values mentioned in the table are based on the following conditions:
– Power source of specifications: 230 V
– Pipe length: 5 m, Height difference: 0 m (Outdoor unit—Indoor unit)
• 2 or more indoor units should be connected.
• The total ability of connected indoor unit is from 14,000 Btu/h up to 26,000 Btu/h.
• Input in the table are calculated based on the maximum indoor unit input combinations.
- 310 -
6-2. Cooling capacity 6. Capacity table
OUTDOOR UNIT AOYG14-18KBTA2 OUTDOOR UNIT AOYG14-18KBTA2
