Fujitsu AOYG14KBTA2 User Manual


Floor type
Model: AGYG09KVCA
Outdoor temperature
Indoor temperature (°CDB)
16.0 18.0 20.0 22.0 24.0
(°CDB) (°CWB) TC TC TC TC TC
-15.0 -16.0 2.04 1.99 1.94 1.89 1.84
-10.0 -11.0 2.34 2.29 2.23 2.18 2.12
-5.0 -7.0 2.65 2.59 2.52 2.46 2.40
0.0 -2.0 3.38 3.30 3.22 3.14 3.06
5.0 3.0 3.78 3.69 3.60 3.51 3.42
7.0 6.0 3.78 3.69 3.60 3.51 3.42
10.0 8.0 3.78 3.69 3.60 3.51 3.42
15.0 10.0 3.78 3.69 3.60 3.51 3.42
20.0 15.0 3.78 3.69 3.60 3.51 3.42
24.0 18.0 3.78 3.69 3.60 3.51 3.42
Model: AGYG12KVCA
Outdoor temperature
Indoor temperature (°CDB)
16.0 18.0 20.0 22.0 24.0
(°CDB) (°CWB) TC TC TC TC TC
-15.0 -16.0 2.50 2.44 2.38 2.32 2.26
-10.0 -11.0 2.88 2.81 2.74 2.67 2.60
-5.0 -7.0 3.25 3.18 3.10 3.02 2.94
0.0 -2.0 4.15 4.05 3.95 3.85 3.75
5.0 3.0 4.64 4.53 4.42 4.31 4.20
7.0 6.0 4.64 4.53 4.42 4.31 4.20
10.0 8.0 4.64 4.53 4.42 4.31 4.20
15.0 10.0 4.64 4.53 4.42 4.31 4.20
20.0 15.0 4.64 4.53 4.42 4.31 4.20
24.0 18.0 4.64 4.53 4.42 4.31 4.20
Model: AGYG14KVCA
Outdoor temperature
Indoor temperature (°CDB)
16.0 18.0 20.0 22.0 24.0
(°CDB) (°CWB) TC TC TC TC TC
-15.0 -16.0 2.64 2.58 2.51 2.45 2.39
-10.0 -11.0 3.04 2.97 2.89 2.82 2.75
-5.0 -7.0 3.44 3.36 3.27 3.19 3.11
0.0 -2.0 4.38 4.28 4.17 4.07 3.96
5.0 3.0 4.90 4.79 4.67 4.55 4.44
7.0 6.0 4.90 4.79 4.67 4.55 4.44
10.0 8.0 4.90 4.79 4.67 4.55 4.44
15.0 10.0 4.90 4.79 4.67 4.55 4.44
20.0 15.0 4.90 4.79 4.67 4.55 4.44
24.0 18.0 4.90 4.79 4.67 4.55 4.44
NOTES:
• TC: Total Capacity (kW)
• Values mentioned in the table are based on the following conditions:
– Pipe length: 5 m, Height difference: 0 m (Outdoor unit—Indoor unit)
- 334 -
6-3. Heating capacity 6. Capacity table
OUTDOOR UNIT AOYG14-18KBTA2 OUTDOOR UNIT AOYG14-18KBTA2

Fujitsu AOYG14KBTA2 Specifications
