Fujitsu ARYG36LMLE User Manual

¢
Cooling capacity (Triple)

Cassette type
Model: AUYG30LRLE × 3
AFR
m
3
/h
4,800
Indoor temperature
°CDB 18 21 23 25 27 29 32
°CWB 12 15 16 18 19 21 23
Outdoor temperature
°CDB
TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP
kW kW kW kW kW kW kW
-15 20.19 17.51 2.75 22.49 17.62 2.79 23.25 19.15 2.81 24.78 19.22 2.84 25.55 20.75 2.85 27.08 20.66 2.89 28.62 22.02 2.91
-10 19.98 17.33 2.76 22.27 17.44 2.80 23.02 18.97 2.81 24.55 19.02 2.84 25.30 20.54 2.86 26.82 20.46 2.89 28.34 21.79 2.91
0 19.80 17.17 2.94 22.05 17.28 2.98 22.80 18.78 3.00 24.30 18.84 3.03 25.05 20.34 3.05 26.57 20.26 3.07 28.07 21.58 3.10
5 19.75 17.13 3.06 22.01 17.23 3.11 22.75 18.73 3.13 24.25 18.79 3.16 25.01 20.29 3.18 26.51 20.21 3.21 28.01 21.53 3.24
10 19.55 17.10 3.45 21.78 17.21 3.50 22.51 18.70 3.52 24.00 18.77 3.55 24.74 20.26 3.57 26.23 20.19 3.61 27.71 21.50 3.65
15 18.99 16.90 3.56 21.14 17.18 3.62 21.87 18.67 3.64 23.30 18.73 3.67 24.02 20.23 3.70 25.47 20.15 3.73 26.90 21.46 3.77
20 19.24 17.06 3.97 21.42 17.35 4.03 22.17 18.86 4.04 23.62 18.91 4.09 24.35 20.44 4.11 25.81 20.35 4.15 27.28 21.67 4.19
25 19.42 17.07 4.71 21.64 17.36 4.78 22.39 18.87 4.80 23.86 18.93 4.85 24.60 20.45 4.87 26.07 20.37 4.92 27.55 21.70 4.97
30 19.05 16.22 5.37 21.22 16.49 5.45 21.95 17.94 5.47 23.38 17.99 5.54 24.11 19.43 5.56 25.55 19.35 5.61 27.00 20.63 5.67
35 17.38 15.85 5.99 19.35 16.21 6.08 20.02 17.63 6.11 21.35 17.68 6.18 22.00 19.10 6.20 23.32 19.02 6.27 24.65 20.26 6.33
40 17.21 14.97 5.67 19.17 15.40 5.75 19.82 16.75 5.79 21.13 16.80 5.84 21.78 18.15 5.87 23.09 18.08 5.93 24.39 19.25 5.99
46 13.70 13.57 5.53 15.27 14.57 5.60 15.78 15.44 5.63 16.81 15.90 5.69 17.35 17.17 5.72 18.39 17.09 5.78 19.42 18.19 5.83

Duct type
Model: ARYG30LMLE × 3
AFR
m
3
/h
5,700
Indoor temperature
°CDB 18 21 23 25 27 29 32
°CWB 12 15 16 18 19 21 23
Outdoor temperature
°CDB
TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP
kW kW kW kW kW kW kW
-15 20.19 15.78 3.03 22.49 15.88 3.08 23.25 17.26 3.10 24.78 17.32 3.13 25.55 18.69 3.14 27.08 18.62 3.18 28.62 19.84 3.21
-10 19.98 15.62 3.04 22.27 15.72 3.09 23.02 17.09 3.10 24.55 17.14 3.13 25.30 18.51 3.15 26.82 18.44 3.18 28.34 19.64 3.21
0 19.80 15.47 3.24 22.05 15.57 3.28 22.80 16.92 3.30 24.30 16.98 3.34 25.05 18.33 3.36 26.57 18.25 3.39 28.07 19.45 3.42
5 19.75 15.44 3.38 22.01 15.52 3.43 22.75 16.88 3.45 24.25 16.93 3.49 25.01 18.29 3.51 26.51 18.21 3.54 28.01 19.40 3.57
10 19.55 15.41 3.80 21.78 15.50 3.86 22.51 16.85 3.88 24.00 16.91 3.92 24.74 18.26 3.94 26.23 18.20 3.98 27.71 19.37 4.02
15 18.99 15.23 3.93 21.14 15.48 3.99 21.87 16.83 4.01 23.30 16.88 4.05 24.02 18.23 4.07 25.47 18.16 4.11 26.90 19.33 4.16
20 19.24 15.37 4.37 21.42 15.63 4.45 22.17 16.99 4.46 23.62 17.04 4.51 24.35 18.41 4.53 25.81 18.34 4.58 27.28 19.53 4.62
25 19.42 15.38 5.19 21.64 15.64 5.27 22.39 17.00 5.29 23.86 17.05 5.35 24.60 18.43 5.37 26.07 18.36 5.43 27.55 19.55 5.48
30 19.05 14.62 5.92 21.22 14.86 6.01 21.95 16.16 6.03 23.38 16.21 6.10 24.11 17.51 6.13 25.55 17.44 6.19 27.00 18.59 6.26
35 17.38 14.28 6.60 19.35 14.61 6.70 20.02 15.89 6.74 21.35 15.93 6.81 22.00 17.21 6.84 23.32 17.14 6.91 24.65 18.26 6.98
40 17.21 13.49 6.25 19.17 13.88 6.34 19.82 15.09 6.39 21.13 15.14 6.44 21.78 16.35 6.47 23.09 16.29 6.54 24.39 17.35 6.61
46 13.70 12.22 6.09 15.27 13.13 6.17 15.78 13.91 6.21 16.81 14.32 6.27 17.35 15.47 6.31 18.39 15.40 6.37 19.42 16.39 6.43

Ceiling type
Model: ABYG30LRTE × 3
AFR
m
3
/h
4,980
Indoor temperature
°CDB 18 21 23 25 27 29 32
°CWB 12 15 16 18 19 21 23
Outdoor temperature
°CDB
TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP
kW kW kW kW kW kW kW
-15 20.19 17.51 2.75 22.49 17.62 2.79 23.25 19.15 2.81 24.78 19.22 2.84 25.55 20.75 2.85 27.08 20.66 2.89 28.62 22.02 2.91
-10 19.98 17.33 2.76 22.27 17.44 2.80 23.02 18.97 2.81 24.55 19.02 2.84 25.30 20.54 2.86 26.82 20.46 2.89 28.34 21.79 2.91
0 19.80 17.17 2.94 22.05 17.28 2.98 22.80 18.78 3.00 24.30 18.84 3.03 25.05 20.34 3.05 26.57 20.26 3.07 28.07 21.58 3.10
5 19.75 17.13 3.06 22.01 17.23 3.11 22.75 18.73 3.13 24.25 18.79 3.16 25.01 20.29 3.18 26.51 20.21 3.21 28.01 21.53 3.24
10 19.55 17.10 3.45 21.78 17.21 3.50 22.51 18.70 3.52 24.00 18.77 3.55 24.74 20.26 3.57 26.23 20.19 3.61 27.71 21.50 3.65
15 18.99 16.90 3.56 21.14 17.18 3.62 21.87 18.67 3.64 23.30 18.73 3.67 24.02 20.23 3.70 25.47 20.15 3.73 26.90 21.46 3.77
20 19.24 17.06 3.97 21.42 17.35 4.03 22.17 18.86 4.04 23.62 18.91 4.09 24.35 20.44 4.11 25.81 20.35 4.15 27.28 21.67 4.19
25 19.42 17.07 4.71 21.64 17.36 4.78 22.39 18.87 4.80 23.86 18.93 4.85 24.60 20.45 4.87 26.07 20.37 4.92 27.55 21.70 4.97
30 19.05 16.22 5.37 21.22 16.49 5.45 21.95 17.94 5.47 23.38 17.99 5.54 24.11 19.43 5.56 25.55 19.35 5.61 27.00 20.63 5.67
35 17.38 15.85 5.99 19.35 16.21 6.08 20.02 17.63 6.11 21.35 17.68 6.18 22.00 19.10 6.20 23.32 19.02 6.27 24.65 20.26 6.33
40 17.21 14.97 5.67 19.17 15.40 5.75 19.82 16.75 5.79 21.13 16.80 5.84 21.78 18.15 5.87 23.09 18.08 5.93 24.39 19.25 5.99
46 13.70 13.57 5.53 15.27 14.57 5.60 15.78 15.44 5.63 16.81 15.90 5.69 17.35 17.17 5.72 18.39 17.09 5.78 19.42 18.19 5.83
- 161 -
6-2. Model: AOYG90LRLA 6. Capacity table
OUTDOOR UNIT AOYG72-90LRLA OUTDOOR UNIT AOYG72-90LRLA

Fujitsu ARYG36LMLE Specifications

General

Type	Air conditioner indoor unit
Multi-split	-
Hose diameter	- mm
Product color	Black, Stainless steel
Dehumidifying capacity	- l/h
Air conditioner functions	Cooling, Dehumidifying, Heating
Refrigerating medium weight	- g
Cooling capacity in watts (nominal)	- W
Operating temperature (cooling) (T-T)	- °C
Current	20 A
AC input voltage	230 V
Current (cooling)	18.5 A
AC input frequency	50 Hz
Design load (cooling)	- kW
Annual energy consumption (cooling)	- kWh
Indoor unit type	Cassette
Indoor unit depth	700 mm
Indoor unit width	1135 mm
Indoor unit height	270 mm
Indoor unit weight	40000 g
Cooling airflow (indoor unit)	1900 m³/h
Indoor unit noise level (high speed)	39 dB
Outdoor unit noise level	- dB
