7-2. Model: AOYG90LRLA
NOTE: Values mentioned in the table are calculated based on the maximum capacity.
COOLING
Pipe length (m)
5 7.5 10 20 30 40 50 60 70 80 90 100
Height difference H (m)
Indoor
unit is
higher
than
outdoor
unit *1
30 — — — — 0.898 0.874 0.850 0.826 0.803 0.780 0.756 0.732
20 — — — 0.938 0.913 0.889 0.864 0.840 0.817 0.793 0.769 0.744
10 — — 0.978 0.953 0.928 0.903 0.879 0.854 0.830 0.806 0.781 0.757
7.5 — 0.988 0.982 0.957 0.932 0.907 0.882 0.858 0.834 0.809 0.784 0.760
5 0.992 0.992 0.986 0.961 0.935 0.911 0.886 0.861 0.837 0.812 0.788 0.763
0 1.000 1.000 0.994 0.969 0.943 0.918 0.893 0.868 0.844 0.819 0.794 0.769
Indoor
unit is
lower
than
outdoor
unit *2
-5 1.000 1.000 0.994 0.969 0.943 0.918 0.893 0.868 0.844 0.819 0.794 0.769
-7.5 — 1.000 0.994 0.969 0.943 0.918 0.893 0.868 0.844 0.819 0.794 0.769
-10 — — 0.994 0.969 0.943 0.918 0.893 0.868 0.844 0.819 0.794 0.769
-20 — — — 0.969 0.943 0.918 0.893 0.868 0.844 0.819 0.794 0.769
-30 — — — — 0.943 0.918 0.893 0.868 0.844 0.819 0.794 0.769
HEATING
Pipe length (m)
5 7.5 10 20 30 40 50 60 70 80 90 100
Height difference H (m)
Indoor
unit is
higher
than
outdoor
unit *1
30 — — — — 0.977 0.966 0.956 0.946 0.938 0.928 0.918 0.908
20 — — — 0.987 0.977 0.966 0.956 0.946 0.938 0.928 0.918 0.908
10 — — 0.997 0.987 0.977 0.966 0.956 0.946 0.938 0.928 0.918 0.908
7.5 — 1.000 0.997 0.987 0.977 0.966 0.956 0.946 0.938 0.928 0.918 0.908
5 1.000 1.000 0.997 0.987 0.977 0.966 0.956 0.946 0.938 0.928 0.918 0.908
0 1.000 1.000 0.997 0.987 0.977 0.966 0.956 0.946 0.938 0.928 0.918 0.908
Indoor
unit is
lower
than
outdoor
unit *2
-5 0.995 0.995 0.992 0.982 0.972 0.961 0.951 0.941 0.933 0.923 0.913 0.903
-7.5 — 0.993 0.990 0.980 0.970 0.959 0.949 0.939 0.931 0.921 0.911 0.901
-10 — — 0.987 0.977 0.967 0.956 0.946 0.937 0.928 0.918 0.908 0.898
-20 — — — 0.967 0.957 0.947 0.937 0.927 0.919 0.909 0.899 0.889
-30 — — — — 0.948 0.937 0.927 0.918 0.909 0.900 0.890 0.880
- 166 -
7-2. Model: AOYG90LRLA 7. Capacity compensation rate for pipe length and height difference
OUTDOOR UNIT AOYG72-90LRLA OUTDOOR UNIT AOYG72-90LRLA

Fujitsu ARYG36LMLE Specifications

General

Type	Air conditioner indoor unit
Multi-split	-
Hose diameter	- mm
Product color	Black, Stainless steel
Dehumidifying capacity	- l/h
Air conditioner functions	Cooling, Dehumidifying, Heating
Refrigerating medium weight	- g
Cooling capacity in watts (nominal)	- W
Operating temperature (cooling) (T-T)	- °C
Current	20 A
AC input voltage	230 V
Current (cooling)	18.5 A
AC input frequency	50 Hz
Design load (cooling)	- kW
Annual energy consumption (cooling)	- kWh
Indoor unit type	Cassette
Indoor unit depth	700 mm
Indoor unit width	1135 mm
Indoor unit height	270 mm
Indoor unit weight	40000 g
Cooling airflow (indoor unit)	1900 m³/h
Indoor unit noise level (high speed)	39 dB
Outdoor unit noise level	- dB
