4-2. Power supply cable wiring
¢
Power supply cable specifications
 Indoor unit
Electrical requirement
Power supply cable
Minimum conductor size
mm
2
1.5
Transmission cable
Bus wire
Minimum conductor size
mm
2
0.33
Maximum length m 500*
NOTES:
• *: This length shall be the total extended length in the system of the group. (Total length of
bus wire and remote controller cable.)
• Use confirmed cable with type 245 IEC 57. (Power supply cable or transmission cable)
• Perform all electrical work according to the standard.
• Install a circuit breakers, which have the terminal spacing of more than 3 mm, in a place of
near the indoor unit and outdoor unit.
• Wiring size must comply with the applicable local and national code.
 Outdoor unit
Breaker and wiring specifications
Breaker capacity A 30
Power supply cable Minimum conductor size
mm
2
6
NOTES:
• Use confirmed cable with type 245 IEC 57.
• Perform all electrical work according to the standard.
• Install a circuit breaker with a contact gap of at least 3 mm in all poles nearby the units.
(Both indoor units and outdoor units)
• Install the circuit breaker nearby the units.
• Wiring size must comply with the applicable local and national code.
- 211 -
4-2. Power supply cable wiring 4. Wiring design
SYSTEM DESIGN SYSTEM DESIGN

Fujitsu ARYG36LMLE Specifications

General

Type	Air conditioner indoor unit
Multi-split	-
Hose diameter	- mm
Product color	Black, Stainless steel
Dehumidifying capacity	- l/h
Air conditioner functions	Cooling, Dehumidifying, Heating
Refrigerating medium weight	- g
Cooling capacity in watts (nominal)	- W
Operating temperature (cooling) (T-T)	- °C
Current	20 A
AC input voltage	230 V
Current (cooling)	18.5 A
AC input frequency	50 Hz
Design load (cooling)	- kW
Annual energy consumption (cooling)	- kWh
Indoor unit type	Cassette
Indoor unit depth	700 mm
Indoor unit width	1135 mm
Indoor unit height	270 mm
Indoor unit weight	40000 g
Cooling airflow (indoor unit)	1900 m³/h
Indoor unit noise level (high speed)	39 dB
Outdoor unit noise level	- dB
