Fujitsu ARYG36LMLE User Manual

2-2. Piping limitation
CAUTION
Keep the “piping limitation” for correct operation.
• Allowable height difference:
– If the height difference between indoor unit and outdoor unit is larger than the allowable value:
The pressure loss will be larger
→ Insufficient cooling and heating
The refrigerant in liquid pipe will flush →
Refrigerant flow noise generate at indoor
unit
The refrigerant oil will not return →
Insufficient refrigerant oil resulting in com-
pressor damage
– If the height difference between indoor units is larger than the allowable value:
The refrigerant flow balance will be poor
→
Insufficient cooling and heating (poor bal-
ance)
Refrigerant oil will collect in the piping or
non-operating indoor units
→
Insufficient refrigerant oil resulting in com-
pressor damage
• Piping length:
If the piping length is longer than prescribed:
The pressure loss will be larger → Insufficient cooling and heating
Too much refrigerant will be charged →
Liquid backs up resulting in compressor
damage
The refrigerant oil will not return →
Insufficient refrigerant oil resulting in com-
pressor damage
• Pipe size:
– If the pipe size is larger than designated size:
The refrigerant flow velocity will drop. Re-
frigerant oil will not return to the outdoor
unit.
→
Insufficient refrigerant oil resulting in com-
pressor damage
The refrigerant in liquid pipe will flush easi-
ly
→ Insufficient cooling and heating
– If the pipe size is smaller than designated size:
The refrigerant circulation volume will drop → Insufficient cooling and heating
The pressure loss will be larger → Insufficient cooling and heating
- 180 -
2-2. Piping limitation 2. Pipe design
SYSTEM DESIGN SYSTEM DESIGN

Fujitsu ARYG36LMLE Specifications

General

Type	Air conditioner indoor unit
Multi-split	-
Hose diameter	- mm
Product color	Black, Stainless steel
Dehumidifying capacity	- l/h
Air conditioner functions	Cooling, Dehumidifying, Heating
Refrigerating medium weight	- g
Cooling capacity in watts (nominal)	- W
Operating temperature (cooling) (T-T)	- °C
Current	20 A
AC input voltage	230 V
Current (cooling)	18.5 A
AC input frequency	50 Hz
Design load (cooling)	- kW
Annual energy consumption (cooling)	- kWh
Indoor unit type	Cassette
Indoor unit depth	700 mm
Indoor unit width	1135 mm
Indoor unit height	270 mm
Indoor unit weight	40000 g
Cooling airflow (indoor unit)	1900 m³/h
Indoor unit noise level (high speed)	39 dB
Outdoor unit noise level	- dB
