Fujitsu ARYG36LMLE User Manual

¢
Wiring method
The wiring method conforms to the following diagram.
3N 400 V ~ 50 Hz
Breaker
3N 400 V ~ 50 Hz
Breaker
Power supply Power supply
Indoor unit
(Transmission)
Indoor unit
(Transmission)
Outdoor unit
Remote control
Remote
controller
Junction box
Remote control Remote control Remote control
Indoor unit
(primary 1)
(primary)
(secondary 1)
(secondary)
(primary 2) (secondary 2)
1 2 3 1 2 3 1 2 3 1 2 3
R W B
1 2 3
1 2 3 1 2 3
1 2 3
1 2 3 1 2 3
1 2 3 1 2 3
1 2 3 1 2 3 1 2 3 1 2 3
R W B
Remote
controller
Outdoor unit1
Outdoor unit2
Junction box1 Junction box2
Indoor unit1 Indoor unit2 Indoor unit3 Indoor unit4
L3L1L2N
L3L1L2N
L3L1L2N
L3L1L2N
- 215 -
4-2. Power supply cable wiring 4. Wiring design
SYSTEM DESIGN SYSTEM DESIGN

Fujitsu ARYG36LMLE Specifications

General

Type	Air conditioner indoor unit
Multi-split	-
Hose diameter	- mm
Product color	Black, Stainless steel
Dehumidifying capacity	- l/h
Air conditioner functions	Cooling, Dehumidifying, Heating
Refrigerating medium weight	- g
Cooling capacity in watts (nominal)	- W
Operating temperature (cooling) (T-T)	- °C
Current	20 A
AC input voltage	230 V
Current (cooling)	18.5 A
AC input frequency	50 Hz
Design load (cooling)	- kW
Annual energy consumption (cooling)	- kWh
Indoor unit type	Cassette
Indoor unit depth	700 mm
Indoor unit width	1135 mm
Indoor unit height	270 mm
Indoor unit weight	40000 g
Cooling airflow (indoor unit)	1900 m³/h
Indoor unit noise level (high speed)	39 dB
Outdoor unit noise level	- dB
