¢ Model: ARYG36LMLE (Static pressure mode 3)
Static pressure (Pa)
55 63 77 89 102 117 130 150
Fan
speed
HIGH
m3/h — — — — — — 1,730 1,500
l/s — — — — — — 481 417
CFM — — — — — — 1,018 883
MED
m3/h — — — — 1,530 1,310 — —
l/s — — — — 425 364 — —
CFM — — — — 901 771 — —
LOW
m3/h — — 1,330 1,140 — — — —
l/s — — 369 317 — — — —
CFM — — 783 671 — — — —
QUIET
m3/h 1,110 960 — — — — — —
l/s 308 267 — — — — — —
CFM 653 565 — — — — — —
Airflow (m
3
/h)
60
150
130
Static pressure (Pa)
900 1,100 1,500 1,700 1,900 2,100 2,300
Q-h Characteristic curve
1,300
50
140
100
90
70
80
120
110
Low
Quiet
Med
Hi
- 85 -
6-2. Duct type 6. Fan performance
INDOOR UNITS SIMULTANEOUS MULTI INDOOR UNITS SIMULTANEOUS MULTI

Fujitsu ARYG36LMLE Specifications

General

Type	Air conditioner indoor unit
Multi-split	-
Hose diameter	- mm
Product color	Black, Stainless steel
Dehumidifying capacity	- l/h
Air conditioner functions	Cooling, Dehumidifying, Heating
Refrigerating medium weight	- g
Cooling capacity in watts (nominal)	- W
Operating temperature (cooling) (T-T)	- °C
Current	20 A
AC input voltage	230 V
Current (cooling)	18.5 A
AC input frequency	50 Hz
Design load (cooling)	- kW
Annual energy consumption (cooling)	- kWh
Indoor unit type	Cassette
Indoor unit depth	700 mm
Indoor unit width	1135 mm
Indoor unit height	270 mm
Indoor unit weight	40000 g
Cooling airflow (indoor unit)	1900 m³/h
Indoor unit noise level (high speed)	39 dB
Outdoor unit noise level	- dB
