3. Select the [Function No.] with pressing the [Cursor button (Left/Right)], and select the Function
No. to be set with pressing the [Cursor button (Up/Down)].
C
ancel
:
OK:
Function s e t ting
Mo 10:00AM
R.C. Function Setting
address No. No.
Version Er r or his t ory
00 30 00
4. Select the [Setting No.] with pressing the [Cursor button (Left/Right)], and select the Setting No.
to be set with pressing the [Cursor button (Up/Down)].
C ancel : OK:
Function s e t ting
Mo 10:00AM
R.C. Function Setting
address No. No.
Version Er r o r his t ory
00 30 01
5. Pressing the [Enter button], confirm the setting.
The data will be transferred to the indoor unit.
C ancel : OK:
Function se t ting
Mo 10:00AM
R.C. Function Setting
address No. No.
Version Err o r hist o ry
00 30 01
C ancel : OK:
Function se t t ing
Mo
10:00AM
R.C. Function Setting
address No. No.
Version Err o r hist o ry
00 30 - -
C ancel : OK:
Function se t t ing
Mo
10:00AM
R.C. Function Setting
address No. No.
Version Err o r hist o ry
00 30 01
Error
Good
Function details: Refer to Chapter 8-6. "Function details" on page 284.
- 273 -
8-3. Indoor unit (setting by wired remote controller) 8. Function settings
SYSTEM DESIGN SYSTEM DESIGN

Fujitsu ARYG36LMLE Specifications

General

Type	Air conditioner indoor unit
Multi-split	-
Hose diameter	- mm
Product color	Black, Stainless steel
Dehumidifying capacity	- l/h
Air conditioner functions	Cooling, Dehumidifying, Heating
Refrigerating medium weight	- g
Cooling capacity in watts (nominal)	- W
Operating temperature (cooling) (T-T)	- °C
Current	20 A
AC input voltage	230 V
Current (cooling)	18.5 A
AC input frequency	50 Hz
Design load (cooling)	- kW
Annual energy consumption (cooling)	- kWh
Indoor unit type	Cassette
Indoor unit depth	700 mm
Indoor unit width	1135 mm
Indoor unit height	270 mm
Indoor unit weight	40000 g
Cooling airflow (indoor unit)	1900 m³/h
Indoor unit noise level (high speed)	39 dB
Outdoor unit noise level	- dB
