TechNotes D323x-S_D3243-S V1.2 Page 22 of 98 http://www.fujitsu.com/fts/products/computing/pc/accessories/mainboards
mainboards
Feature Overview
2.12 Summary: Feature Differences D323x-S
Feature
D3231-S
D3236-S
D3235-S
D3243-S
Chipset (PCH)
Q87
Q87
H81
Q87
Memory Sockets / max. RAM
4 / 32GB
4 / 32GB
2 / 16GB
2 / 16GB
PCIe x16 (PEG Slot) [Note: Lane splitting not possible!]
Gen3
Gen3
Gen2
Gen3
PCIe x16- 16 lanes / PCIe x16- 4 lanes/ PCIe x16- 2 lanes /
PCIe x8- 1 lane / PCI
1 / 1 / -- / 1 / 1
1 / 1 / -- / 1 / 4
1 / -- / 1 / 1 / 4
1 / -- / -- / -- / --
mSATA Socket / Mini-PCIe Socket / 8 Bit GPIO / TPM V1.2
x / -- / x / x
x / -- / x / x
-- / -- / -- / --
x
3)
/ x / x / x
USB2.0 Ports internal / external
4
1)
/ 6
4
1)
/ 6
2 / 6
3
2)
/ 6
USB3.0 Ports internal / external
2 / 2
2 / 2
2 / --
3
2)
/ 2
Supported Fans / PowerSupply Fan Control
4 / x
4 / x
2 / x
2 / x
SATA2 / SATA3
-- / 6
-- / 6
3 / 2
-- / 5
S-PDIF / Intrusion / SCSI LED
x / x / x
x / x / x
-- / -- / x
x / x / --
COM-Port external / COM-Port internal / Parallel Port internal
1 / 1 / 1
1 / 1 / 1
-- / 1 / 1
1 / 1 / 1
DVI-I / DisplayPort 1 / DisplayPort 2 / LVDS
x / x / x / --
x / x / x / --
x / x / -- / --
x / x / x / x
Dual LAN / Intel iAMT 9.1 - vPro 2014 Manageability
x / x
x / x
-- / --
x / x
BIOS-POST / BIOS-Boot / OS – HW Watchdog onboard
x / x / x
x / x / x
x / x / x
x / x / x
EraseDisk (BIOS Feature) included
x
x
x
x
1) Therof two ports used for USB stick (dongle) and mSATA socket 2) Thereof 1x USB3.0 for USB stick (dongle) and 1 x USB 2.0 for Mini-PCIe
3). Fullsize slot switchable between mSATA or Mini-PCIe (BIOS Option)

Fujitsu D3236-S Specifications

General

Brand	Fujitsu
Model	D3236-S
Category	Motherboard
Language	English
