TechNotes D323x-S_D3243-S V1.2 Page 72 of 98 http://www.fujitsu.com/fts/products/computing/pc/accessories/mainboards
mainboards
Display Options
6.14 LVDS – Influence on Graphics Output D3243-S [New]
When LVDS support is enabled in BIOS Setup of D3243-S, this has some effect on the support of the other graphics output ports (DVI-D, VGA via DVI-I, DisplayPort).
Furthermore, the setting “Secure Boot” (required for Windows 8.1) also influences the supported graphics output modes.
Important note: If Secure Boot is enabled, the System BIOS uses the GOP (Graphics Output Protocol) graphics driver. In addition, there is another BIOS Setup option
available (in Secure Boot mode only!): AMI Graphic Output Protocol Policy.
The settings in this menu should never be changed, otherwise any video outputs may be inaccurate!
Do NOT touch / change these settings!
BIOS Setup option to select Secure Boot:
Disabled for MS Windows 7 (=default)
Enabled for MS Windows 8.1
Additional BIOS Setup graphics option,
available in Secure Boot mode only
