TechNotes D323x-S_D3243-S V1.2 Page 68 of 98 http://www.fujitsu.com/fts/products/computing/pc/accessories/mainboards
mainboards
Display Options
6.12
LVDS Timing & Screen Resolution (D3243-S)
There are 9 default LVDS settings available
BIOS Setup Advanced LVDS Config Select
Note: Option 10 (LVDS adjusted Parameters)
becomes visible after running the “LVDS Tool”
for implementing customized LVDS settings
once.
Important note:
“Non-EDID Support” must be set to
<Enabled> for standard LVDS displays
w/o DDC (EDID) interface!
