Fujitsu fi-4860C2

3-43
3.8 Cleaning the Lamps
3
DAILY CARE
3. Pull down on the tab to release the Lamp socket covers attached to the
both ends of the Lamp to remove them.
4. Rotate the Lamp a half turn so that the terminals on each end align with
the slot on the Lamp socket. Then remove the Lamp from the socket.
Tab
Lamp socket
