5-4
5.1 Clearing Document Jams
■ Removing jams from the eject mechanism.
1. Remove the documents on the stacker. Pull up the lever on the right front
of the Upper transport and then raise it.
2. Pull out the jammed document to the stacker.
3. Lift the Upper transport unit to release the safety lock, then lower the unit
carefully and push the unit to close it completely.
ADF upper sheet guide
ADF release lever
To Next Page
