2-13
2.5 Detecting Double-Feeds (Multi-Feeds)
2
SCANNING VARIOUS TYPES OF DOCUMENTS
2.5 Detecting Double-Feeds
(Multi-Feeds)
"Double-feed" (also known as "Multi-feed") is an error that occurs when two or more sheets are
accidentally fed into the ADF at the same time. You can set the scanner to display an error
message when it detects a double-feed.
To set conditions for the double-feed detection, change the settings in the driver setting dialog
box. The following shows examples for changing the settings in the [TWAIN Driver] dialog box.
The following shows the procedure for changing the settings in the dialogbox.
1. Click the [Option...] button in the [TWAIN Driver] dialogbox.
⇒ The [Option] dialogbox appears.
2. Click the [Job/Cache] tab.
To Next Page
