●xxii
4 REPLACEMENT OF CONSUMABLES .... 4-1
Consumables and Replacement Cycle ............................. 4-2
How to check the Abrasion Counter ................................. 4-3
Replacing the Pad ASSY .................................................. 4-4
Replacing the Pick Roller Unit .......................................... 4-9
Replacing the Brake Roller Unit ...................................... 4-12
Replacing the Front-side Lamp ....................................... 4-15
Replacing the Back-side Lamp ....................................... 4-20
5 SOLVING COMMON PROBLEMS ........... 5-1
Clearing Document Jams ................................................. 5-2
Troubleshooting ................................................................ 5-8
Before Contacting a Service Provider ............................. 5-29
Labels on the Scanner .................................................... 5-31
6 ADF DOCUMENT SPECIFICATIONS ...... 6-1
Document Size ................................................................. 6-2
Document Quality ............................................................. 6-3
Hole-punching Prohibited Areas ....................................... 6-6
Print Prohibited Area ......................................................... 6-7
Background Color Areas ................................................... 6-8
Job Separation Sheet ....................................................... 6-9
Hopper Capacity ............................................................. 6-10
7 OPERATOR PANEL MENUS ................... 7-1
Setup Mode ...................................................................... 7-2
Setup mode functions ....................................................... 7-9
Setup Mode Details ........................................................ 7-16
Test Mode Overview ...................................................... 7-67
Test Mode Details ........................................................... 7-72
8 OPTIONS .................................................. 8-1
Options ............................................................................. 8-2
fi-486PRFR (Pre-imprinter) ............................................... 8-3
fi-486PRRE (Post-imprinter) ............................................. 8-4
fi-486TRK (Thinner paper Roller Kit) ............................... 8-5
