Fujitsu fi-5900C

4
1.1 Names and Functions of Parts
■ Removable Parts
No. Name Description
1 Document smoother Attached when the stacker position is set to align the ejected document by
the leading edge (see page 24), or when scanning documents with different
widths (see page 71).
2 Pick Rollers Rollers that pick the paper from the hopper into the ADF. This is a con-
sumable item.
3 Separator rollers Roller used to help separate the paper as the feeding begins. This is a con-
sumable item.
4 Brake rollers Roller used to help separate the paper as the feeding begins. This is a con-
sumable item.
5 Pad Separation Pad used to help separate the paper as the feeding begins. This
is a consumable item.
S
e
n
d
to
S
c
a
n
P
o
w
e
r
T
h
ic
kne
s
s
Hopper Heigh
t
F
un
c
tio
n
T
hick
Thi
n
1
2
3
4
5
