Fujitsu MCE3064AP - Mode Parameter List; Mode Parameter Header; Page Descriptor

C156-E142-02EN 4 - 43
Table 4.48 lists the mode parameter list.
Table 4.48 Mode parameter list
Bit
Byte
76543210
0-7 Mode Parameter Header
0-n Page Descriptor(s)
The mode parameter list consists of a mode parameter header and page descriptor. Table 4.49 lists
the mode parameter header.
Table 4.49 Mode parameter header
Bit
Byte
76543210
0-1 Mode Data Length
2 Medium Type Code
3 WP Reserved
4-7 Reserved
Mode Data Length must be 0. If any other value is specified, the command ends abnormally with
Check Condition.
The value in Medium Type Code and WP are ignored.
Table 4.50 lists the page descriptor.
Table 4.50 Page descriptor
Bit
Byte
76543210
000 Page Code
1 Page Length (n-1)
2-n Mode Parameters
