Fujitsu MCE3064AP - Surface Temperature Measurement Points

3 - 2 C156-E142-02EN
(a) Inside optical disk cartridge
(b) IC (controller, read map)
Figure 3.1 Surface temperature measurement points
Hole for inserting thermocouple
IC (controller)
IC (read amp)
Tip of thermocouple
Operating of inner
partition wall
