C156-E142-02EN 3 - 19
(5) Transportation
a) Transport the package with the UP sign upward.
b) After unpacking, minimize the transportation distance and use cushions to avoid shock and
vibration. Transport the drive in one of the orientations described in Subsection 3.2.2 after
unpacking. (The horizontal direction is recommended.)
(6) Storage
a) Use moistureproof packaging when storing the drive.
b) The storage environment must satisfy the requirements specified in Subsection 2.1.3 when the
drive is not operating.
c) To prevent condensation, avoid sharp changes in temperature.
Figure 3.17 Gathered packaging style
Figure 3.16 Individual packaging style
Conductive bag
box
Master carton
(12/24 units)
Shipping Label (2)
Support (Middle)
Support (Front, Rear)
Eject Pin (
%
20)
Eject pin (Use a sealing tape)
Desiccant
Desiccant
MCE3130AP,
MCE3064AP, MCF3064AP
To Next Page
