58 Disassembly and Recycling Instructions CX400 M4
Disassembly and recycling
Removing the memory slot air duct (Air cooling only)
Figure 71: Removing the memory slot air duct
Ê Pull up the air duct in a vertical motion and remove it from the chassis.
Removing main memory modules
Figure 72: Removing memory modules (A)
Ê Eject the desired memory module by pressing out the securing clips at each
end of the memory slot.
Figure 73: Removing memory modules (B)
Ê Remove the ejected memory module.
