CX400 M4 Disassembly and Recycling Instructions 57
Disassembly and recycling
Removing the OCP mezzanine card
Figure 70: Removing the OCP mezzanine card
Ê Disengage the OCP mezzanine card from the hooks (see circle) and remove
it from the guide pins.
1.3.6 Removing main memory modules
Tools: tool-less
Recycling parts
Memory modules, 1x memory slot air duct (if air cooling)
Plastic
Printed circuit
