CX400 M4 Disassembly and Recycling Instructions 69
Disassembly and recycling
1.3.9 Removing the iRMC microSD card
Figure 92: Removing the iRMC microSD card
Ê To eject the iRMC microSD card, gently push it in and then let go (1).
Ê Pull the iRMC microSD card straight out of its slot (2).
1.3.10 Removing M.2 SSDs
Tools: tool-less
Recycling parts
1x iRMC microSD card
Plastic
Tools: Phillips PH1 / (+) No. 1 screw driver
Recycling parts
1x or 2x M.2 SSD
Metal
Plastic
Printed circuit
