CX400 M4 Disassembly and Recycling Instructions 17
Disassembly and recycling
Removing the PSU dummy module
Figure 10: Removing the PSU dummy module
Ê Press the handles of the PSU dummy module in the direction of the arrows
(1).
Ê Pull the PSU dummy module out of the bay (2).
1.2.4 Removing fan modules
Tools: tool-less
Recycling parts
8x fan modules
Metal
Plastic
Cables
