Fujitsu PRIMERGY RX200 S3 - Replacing the Control Panel Kit

20 Service Supplement RX200 S3
Replacing the control panel kit Replacing components
4.4 Replacing the control panel kit
Requirements
– The server has been switched off
– The power cables have been uplugged
– The housing cover has been removed
Figure 5: Removing the control panel
Ê Undo the knurled screw (1) and unplug the control panel plug (2).
2
1
