RX200 S3 Service Supplement 33
Settings Power-sharing board
5.4 Power-sharing board
Part number: SNP:A3C40073782
Figure 16: Connectors of the power-sharing board (power backplane)
# Connection
1 Power supply unit fan 1
2 Power supply unit fan 2
3 Power supply unit fan 3
4 Error LED
4
1
2
3
