Fujitsu PRIMERGY RX200 S3 Service Supplement

RX200 S3 Service Supplement 35
6Cabling
6.1 Cable overview
# Part number Description From To
1a (soldered to Power-
sharing Board)
Main Power cable Power-
sharing Board
System board
D2300
1b (soldered to Power-
sharing Board)
PBL-I²C Bus cable Power-
sharing Board
System board
D2300
1c (soldered to Power-
sharing Board)
AUX voltage cable Power-
sharing Board
Fan backplane
and SAS back
-
plane
2 SNP:A3C40073838
Order No.:
A3C40073837
IDE interface cable
for CD/DVD
System board
D2300
Fan back-plane
3 SNP:A3C40073828
Order No.:
A3C40073827
32 pin SAS cable System board
D2300
SAS backplane
4 SNP:A3C40073830
Order No.:
A3C40073829
Front panel cable System board
D2300
Front-panel
board
5 SNP:A3C40073836
Order No.:
A3C40073835
Fan control cable System board
D2300
Fan back-plane
6 SNP:A3C40073832
Order No.:
A3C40073831
LED cable System board
D2300
SAS backplane

Fujitsu PRIMERGY RX200 S3 Specifications

General

Number of Processors	2
Storage	Up to 6 x 3.5" SAS/SATA HDD
RAID Support	RAID 0, 1
Network	Dual Gigabit Ethernet
Form Factor	1U Rack
Power Supply	Hot-plug redundant power supply
