30 Service Supplement RX200 S3
Backplanes for SAS drives Settings
5.2 Backplanes for SAS drives
5.2.1 SAS backplane for 3.5-inch drives
Part number: SNP: A3C40073766
Bild 13: Connector assignment of the SAS backplane
# Connection
1 LED cable
2 Auxiliary power supply for the SAS backplane
3 SAS data cable
1
2
3
