5.2 SAS boards
5.2.1 SAS board for 3.5-inch drives
Part number: SNP: A3C40092046
Figure 16: SAS board for 3.5-inch hard disks
# Connection
1I
2
C cable
2 Power supply for the SAS board
3 SAS data cable
1
2
3
