RX200 S4 Service Supplement 7
Notational conventions
1.2 Notational conventions
The following notational conventions are used in this manual:
Replacement routines:
– Replacing the front panel module
– Replacing the chassis ID/temperature sensor
– Replacing the fan board
– Replacing the SAS board for 3.5-inch drives
– Replacing the SAS board for 2.5-inch drives
– Replacing the power-distribution module
– Replacing the system board
Service Supplement
Board layout
BIOS setup “BIOS Setup“ manual
Italics indicates commands or menu items.
“Quotation marks” indicate names of chapters and terms that are being
emphasized.
Ê describes activities that must be performed in the order
shown.
V CAUTION! pay particular attention to texts marked with this symbol.
Failure to observe this warning may endanger your life,
destroy the system or lead to the loss of data.
I indicates additional information, notes and tips.
Table 2: Notational conventions
Information/activity Manual
Table 1: Overview of the documentation (part 2 of 2)
To Next Page
