Fujitsu Primergy RX200 S4 Service Supplement

6 Service Supplement RX200 S4
Overview of the documentation Preface
© cognitas. Gesellschft für Technik-Dokumentation mbH 2008 Pfad: J:\RX200S4\Doku\Suppl\EN\rx200s4-ss-en.k01
Information/activity Manual
Detailed safety notes “Safety notes and other
important information“
manual
Features and technical data of the server Operating Manual
Installation and operation, among other things:
– External ports
– Operation
– Configuration of the server
– Installation of the rack mounting kit
Troubleshooting
Installation/removal or replacing of the CSS
components:
– Hot-plug power supply units
– Hot-plug HDD modules
– Hot-plug system fans
– Memory modules
– Expansion boards
Information about the system board:
– Features of the system board
– Connector assignment
– Jumper settings
– Replacing the battery
Technical Manual
Extensions and upgrades:
I For some components only the installation
routine is described in the Options Guide.
Removing these components proceed in
reverse order.
– Installing a second processor/replacing the
processor/heat sink
– Extending/replacing the main memory
– Installing an accessible drive
– Installing LSP/LSD
– Installing expansion boards
– Installing an iBBU
– Cabling
Options Guide
Table 1: Overview of the documentation (part 1 of 2)
