Fujitsu Primergy RX200 S4 - SAS Board for 2.5-Inch Drives

RX200 S4 Service Supplement 33
Board layout SAS boards
5.2.2 SAS board for 2.5-inch drives
Part number: SNP: A3C40092033
Figure 17: SAS board for 2.5-inch hard disks
# Connection
1 Power supply for the SAS board
2I
2
C cable
3 SAS data cable
1
2
3
